Anthracite 107° Lift-Up Hinge Air System, Medium-Duty Soft-Close Vertical Opening Hinge (1-Pair)

Description

The Atmos opening system is designed to allow an ascending opening of a drawer door or kitchen cabinet door. Discreet and elegant, the Atmos opening system includes a hinge-free mechanism that is easy to install in your cabinet thanks to the included drilling template. This system offers 3 power factors for light, medium, and heavy loads, allow you to cover a wide variety of applications according to your needs.

• California residentssee Prop 65 WARNINGS
• Type of opening: lift-up opening
• Fits door type: wood door, wide aluminum-framed door
• Power factor: 1105 to 1920 (power factor is equal to cabinet height in mm x (door weight in kg plus 2 x handle weight in kg)
• Motion technology: stay open, soft-close
• Door height: 7-7/8 in. to 19-5/8 in. (200 mm to 500 mm), door length: maximum 47-1/4 in. (maximum 1200 mm)
• Mechanism strength: medium-weight
• System name: aiR range – Atmos series
• Side: left and right
• Finish: anthracite
• Material: metal, plastic
• Screw/nail: included
• Standards and certifications: KCMA
• Hinge opening angle: plus 107°
• Packaging format: pair
• Integrated soft-close mechanism works without hinges smooth opening without resistance stays open in any position, tested and certified (60,000 cycles), atmos is covered by Richelieu Hardware’s limited lifetime warranty
• Opening system is offered as a set that includes everything you need for installation: 2-mechanisms 2-caps 2-door adaptors screws drilling template
• Consult the installation manual to choose the proper power factor for your door
• For wood doors with large aluminum frames for cabinets with a height between 7-7/8 in. (200 mm) and 19-11/16 in. (500 mm) for cabinets with a maximum width of 47-1/4 in. (1200 mm)
